SymPy Editor

A click-to-edit editor for SymPy expressions: select a piece of a formula and change it in place - type over it, apply any SymPy function to it, pull it apart - with the formula drawn as mathematics the whole time, never as code. It runs in the browser, in a Jupyter notebook, or as an app.

Every edit is a step, and the steps make a history: what changed, what produced it, and what it became. The viewers further down are that history, and they do not need the editor at all - a derivation computed in Python is shown the same way. Here are 10 of them.

Open standalone editor Source on GitHub pip install sympy-editor

Try it

A short tour plays here: the editor at work, pressed and typed into for real. Stop it whenever you like, and the editor is yours — click any piece of the formula and change it in place. Python runs in your browser, and every result is computed on your device.

Use it

In a Jupyter notebook

The widget runs every edit in the kernel's own SymPy: w.expr is the live, edited expression.

pip install "sympy-editor[jupyter]"

from sympy import symbols, sin
from sympy_editor import edit

x = symbols("x")
w = edit(sin(x) / x)  # click it, edit in place
w.expr                # what it is now, live
w.on_change(lambda e: print("now:", e))

A page of its own

One self-contained file whose edits run in the browser — or a local server that hands the result back to Python.

from sympy_editor import save_html, serve

save_html(expr, "expr.html")  # one file, no server
new = serve(expr)             # blocks until Done

A history from plain Python

The viewer on this page needs no editor: a list of expressions and a word about each step is enough.

from sympy_editor import History
from sympy_editor import save_history_html

steps = History([
    Integral(x * sin(x), x),
    (-x * cos(x)
     + Integral(cos(x), x), "by parts"),
    (-x * cos(x) + sin(x), "the last integral"),
])
save_history_html(steps, "steps.html")

In the notebook

The widget in JupyterLab: the formula is the interface — click a piece to select it, type over it, or apply any SymPy function; the kernel computes, and w.expr follows.
Two widgets wired together in a notebook: every edit committed in the editor redraws the plot (examples/plot_alongside.ipynb in the repository).

On a phone

The editor on Android: the Gaussian integral selectedA derivation's history on Android, each step's change in red and green
The Android app: the same editor with CPython and SymPy packaged inside, so every edit — and every step of a history — is computed on the phone, offline.

Worked derivations

7 steps

The quadratic formula, by completing the square

Completing the square, which is where the formula comes from.

8 steps

The Gaussian integral

The trick worth knowing: square it, and the plane is polar.

5 steps

The geometric series

Why 1/(1-x), in the two lines it takes.

7 steps

Euler's identity

The most famous identity, through the series that make it obvious.

5 steps

The derivative of x³ from first principles

What a derivative is, before any rule for computing one.

6 steps

Partial fractions, and the integral they unlock

Splitting a fraction is what makes it integrable.

8 steps

The eigenvalues of a 2×2 matrix

Where eigenvalues come from: a determinant that must vanish.

7 steps

Gaussian elimination on a 3×3 system

A system of equations, solved the way it is solved on paper.

6 steps

The harmonic oscillator, from its Lagrangian

Physics in one page: a Lagrangian in, an equation of motion out.

5 steps

Least squares and the normal equations

Why the normal equations look the way they do.
